Model Comparison
Compare Monitor Models

DM231

23.8"
FHD
LCD
Panel Specifications
Screen Size
23.8"
Resolution
1920x1080
Bit Depth (Color)
8bit (16.7 Million Colors)
Contrast Ratio
1500:1
Backlight
Wide Gamut W-LED
Pixel Efficiency
99.999%
Max Luminance
300nits
Viewing Angle
179°
Maximum Native Color Gamut
Max Native Color Gamut
Inputs
1 x DVI-D
DVI Digital
2 x BNC
3Gbps/HD/SD-SDI
1 x DP
DisplayPort
Outputs
2 x BNC
3Gbps/HD/SD-SDI
2 x BNC
2nd Monitor Outputs (Can Mirror On Screen View, Apply LUT, etc.)
Supported SDI Formats
ITU-R BT.656 (PAL)
576i (50)
SMPTE-125M
480i (59.94)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24PsF/23.98/23.98PsF)
SMPTE-296M
720p (60/59.94/50/30/29/25/24/23.98)
2K
2048x1080 (30p/30PsF/29.97p/29.97PsF/25p/25PsF/24p/24PsF/23.98p/23.98PsF)
SMPTE-372M
1080p (50/59.94/60) 4:2:2 YCbCr, RGB
1080i (29.97/25/24/23.98) 4:4:4 YCbCr, RGB
1080p (30/29.97/25/24/23.98) 4:4:4 YCbCr, RGB
720p (60/59.94/50) 4:4:4 YCbCr, RGB
SMPTE-425M-AB
- Level A & Level B supported
- Level B supports 2 x SMPTE
292M image format mapping
372M image format mapping
- RGB, YCbCr, & XYZ supported
12 & 10bit 4:2:2 1920x1080p (60/59.94/50)
4:4:4 1280x720p (60/59.94/50/30/29.97/25/24/23.98)
12 & 10bit 4:4:4 1920x1080i (60/59.94/50)
12 & 10bit 4:4:4 1920x1080p (30/29.97/25/24/23.98 + PsF variations)
12 & 10bit 2k (2048x1080)p (30/29.97/25/24/23.98 + PsF variations)
12 & 10bit 2K (2048x1080)p (60/59.94/50/48/47.95)
*XYZ mapped to Selected Color Gamut on Color Management Menu
Supported DVI Formats
DVI-Digital
VGA (640x480), NTSC (720x480), SVGA (800x600), XGA (1024x768), SXGA (1280x1024), 1280x720, 1440x900, 1920x1080
Audio
Audio Disembedding
Yes
Audio Level Meters
Yes
Internal Speakers
2
Audio In (Mini-Jack)
1
Audio Out (Mini-Jack)
1
Features
Rack Mount Kit
Optional
Removable Desktop Feet
Standard
External Mounting Points
100mm VESA
VESA to Light Stand Mount
Optional
Carrying Case with Integrated Hood
FSI Solutions CH25
Clear Protective Cover
Optional
Scopes
Yes
Measurement Function
Yes
Timecode Display (SD/HD-SDI)
LTC, VITC 1, VITC 2
1:1 Pixel Mapping
Yes
Blue Only & Mono Mode
Yes
Side by Side Monitoring
Yes
3D LUT Color Space Selection
SMPTE C/EBU/REC709/REC2020 Emulation/DCI P3/USER
Color Temperature Select
3200K, 5000K, 5600K, 6500K, 9300K
Gamma Selection
1.0 / 1.8 / 2.0 / 2.2 / 2.35 / 2.4 / 2.6 / 2.8
Power
AC Input
IEC / C14
DC Input
4 PIN XLR
Battery Plate
Optional
Power Requirement
100~240 VAC / 12~24 VDC
DC Power Consumption (Appx.)
22w Normal Mode, 34w Outdoor Mode
Physical Characteristics
Weight (without desktop feet)
12.4 lbs (5.6 kg)
Weight with desktop feet
12.8 lbs (5.8 kg)
Weight in Carrying Case with Hood
(Optional)
19.8 lbs (9 kg)
Chassis
Aluminum Frame
Dimensional Drawing
